How to Set-up: August Connect with Yale Locks
Purchase Scenario |
Instructions |
Purchased from Lynx as a spare order. Email support@getlynx.co for your August account information. |
Do steps 4, 6, & 8 only. Lynx has already completed other steps. |
Purchased from Lynx as a drop-ship/non-programmed order |
Do all steps |
Purchased from another retailer. |
Do all steps |
Before you begin you will need...
- Wifi Credentials of the property/unit (only supports 2.4GHZ)
- August Home app on Android or iPhone
- August account.
- Lock installed with August Module connected and batteries inserted.
- These Modules come in black and white. The older ones are white and the newer ones are black.
- August Bridge plugged in within 15 feet of the Lock.
August bridge must be in direct line of sight to the lock. Avoid disturbances from furniture,
appliances, closet doors, fish tank, metal surfaces for stable connectivity between the
bridge and the lock.
The Process:
Step 1: August Account | Sign up/ Create your August account if you don't have one. Otherwise, skip this step. |
Step 2: Lock master code |
Create Master/ Programming code on the lock, if you haven't done so. Press the following sequence directly on the keypad of the lock. Gear>1>Gear>5 digit master code of your choice>Gear>Gear |
Step 3: Activate 'August' module. |
Activate the August module by pressing the following sequence directly on the keypad of the lock. master code (you created in Step 3)>Gear>7>Gear>3>Gear |
Step 4: Log in to App |
|
Step 5: Lock Setup |
|
Step 6: Bridge Setup |
|
Step 7: Add to Lynx |
|
Step 8: Test from Lynx | Follow instructions for Testing a NEW Lock |
Finish the Groups and User Setup Checklist: Users and Groups |
