How To: Reset Z-Wave Connection with Yale Lock – Lynx

How To: Reset Z-Wave Connection with Yale Lock

To reset the Z-Wave connection on the Yale Lock you will need the following:

1. SmartThings (Lynx) Hub - Plugged into power and connected to the internet either with an
    Ethernet or Wireless connection - when connected the Hub will show a solid green light.
2. A Mobile Device (Phone or Tablet).
3. Master Code for the lock(s) that you are working with.

On your mobile device, you will need to download the SmartThings App (be sure not to download the 'classic version of the App. Reference the icon below.

Once you have the App downloaded on your mobile device: Log in to your account to begin the process. If you do not have the necessary credentials, contact Lynx Support

Step 1:

Z-Wave exclusion

Before you are able to pair a Yale Lock you should first reset the Z-Wave connection to ensure it is not paired with any other devices.

Step 2:

In the SmartThings Mobile App:

From the Home screen select Devices.
Click on Hub and select More Options on the right upper corner
Touch Z-Wave utilities and select Z-Wave exclusion
When prompted for the removal process:
Touch the screen
Enter the 4-8 digit Master Pin followed by the # key
Touch 7 followed by the # key
When prompted, touch 3 followed by the # key

After the app indicates that the device was successfully removed from SmartThings, proceed to connect the lock

Learn how to Unpair a Yale Lock with Samsung Hub after you have created a group.
